KDC300
Product Name
COMPACTOR
Product Series
KDC50, KDC150, KDC200, KDC300
Application
Suitable for most excavator.
Shipping
All country
Features
KD Vibratory Plate Compactor provide superior compaction force in a reliable, low-maintenance package. This attachment is theideal tool when it comes to compaction of soil in trenches, drive sheeting or posts, foundations and slope applications.
Special Features
1. Strong & stable demolition power
2. Automatic rotational positioning with hydraulic motor
3. 360¡Æ Rotating system
4. High-wear resistance material (Hardox)
Specification
| Model | Unit | KDC50 | KDC150 | KDC200 | KDC300 |
| Impulse Force | Ton | 4 | 6.5 | 15 | 15 |
| Vibration Frequency | Rpm | 2000 | 2000 | 2000 | 2000 |
| Oil Flow | L/min | 45~75 | 85~105 | 120~170 | 120~170 |
| Operating Pressure | kg/cm©÷ | 100~130 | 100~130 | 150~200 | 150~200 |
| Weight | kg | 400 | 750 | 1000 | 1100 |
| Bottom Measurement | (LxWxT) mm | 900x550x25 | 1160x700x28 | 1350x900x30 | 1350x900x30 |
| Height | mm | 760 | 920 | 1060 | 1100 |
| Width | mm | 550 | 700 | 900 | 900 |
| Suitable Excavator | ton | 4-9 | 11-16 | 17-23 | 23-30 |
1. Simple structure, easy operation and convenient in use and maintenance.
2. It can complete plane, bevel, step, ditches and pits compaction and tamping of other complex foundations.
